What ANSI 107 Actually Means
When people say a vest is "ANSI rated," they are talking about ANSI/ISEA 107, the standard published by the International Safety Equipment Association. It sets the performance rules for high-visibility safety apparel: how much bright-background fabric a garment carries, how much reflective tape it has, and where that material is positioned on the body.
The standard sorts apparel into three types based on the work environment:
- Type O (off-road): for workers away from public traffic, such as in warehouse yards or parking areas.
- Type R (roadway): for anyone exposed to public traffic or construction vehicles.
- Type P (public safety): for police, fire, and EMS who need visibility plus room for their gear.
Type O apparel is always Class 1. Type R and Type P apparel come in Class 2 or Class 3. For road crews, you live almost entirely in Type R, which means your real choice is Class 2 or Class 3.
The Three Classes Of High-Visibility Apparel
Understanding the types of vests on the market starts with the three performance classes. More fabric and more coverage move you up the scale.
- Class 1: The lowest level of high visibility. Fine for off-road, low-speed settings under 25 mph. Think parking attendants or warehouse staff, not roadway crews.
- Class 2: The baseline for anyone working near moving traffic. It carries at least 775 square inches of background material and more reflective tape than Class 1.
- Class 3: The highest visibility level, with at least 1,240 square inches of background material and coverage that reaches the arms, and sometimes the legs.
Class 2 vs Class 3: The Difference That Matters
Class 2 makes a worker visible. Class 3 makes a worker unmissable from every angle, including in the dark.
A Class 2 garment is usually a vest. It wraps the torso in bright fabric and reflective tape, which is enough for daylight work in moderate traffic. A Class 3 garment has to cover more of the body, so it includes sleeves or is paired with matching high-visibility trousers or sleeves to meet the coverage minimum. That added material is what lets a driver pick out the shape of a human being at highway speed or in headlights, instead of just a floating glow.
The factors that push a job from Class 2 up to Class 3 are speed, light, and complexity:
- Traffic speed: The faster vehicles move, the sooner a driver needs to see the worker. High-speed corridors call for Class 3.
- Lighting: Night work, dusk, dawn, fog, and rain all reduce sight distance. Low light points to Class 3.
- Task and background: Crews on foot near equipment, in cluttered visual backgrounds, or with their attention on the work, benefit from the extra coverage.
When Is Each Class Required On A Job Site
This is where a lot of foremen get tripped up, because the answer is not only a matter of preference. It is federal law.
The FHWA Worker Visibility Rule, found in 23 CFR Part 634, requires every worker inside the right-of-way of a federal-aid highway who is exposed to traffic or construction equipment to wear high-visibility apparel that meets ANSI/ISEA 107. In plain terms, Class 2 is the floor for roadway crews. There is no compliant option below it once you are near public traffic.
Where are Class 2 safety vests required? On most daytime roadway work in moderate-speed zones: flagging in a 35 mph corridor, utility crews in the right-of-way, survey teams, and general construction near active lanes. It is the everyday standard for a lot of what road crews do.
Class 3 becomes the expectation when risk climbs. Reach for Class 3 apparel for high-speed highway work, any nighttime operation, poor-weather visibility, and situations where flaggers or spotters stand directly in the path of oncoming traffic. Many state DOTs and prime contractors write Class 3 into their specs for these conditions, so it pays to read the contract before the crew shows up in vests alone.
Common Questions From The Field
Do all Class 3 vests have sleeves? Not always as a single piece, but the coverage has to be there. A garment reaches Class 3 either by having built-in sleeves or by combining a Class 3 vest with high-visibility sleeves or trousers. A plain sleeveless vest cannot meet Class 3 on its own.
Is there such a thing as a "Class 2 Level 2" vest? That phrasing usually mixes up two things. ANSI 107 uses performance classes, not levels. If a spec calls for Class 2, you need a Class 2 garment. Keep it simple and match the class named in the standard.
Does the vest need to be a specific color? ANSI 107 allows fluorescent yellow-green, fluorescent orange-red, or fluorescent red as compliant background colors. Crews often standardize on one, so workers read as a unit and stand out against the job's specific backdrop.
Getting Your Crew Compliant
